Fire-Lite MR-101/CR Single SPDT Relay with LED
The MR-101/C Multivoltage Control Relays offer SPDT 10 Amp resistive contacts which may be operated by one of four input control voltages. A single relay may be energized from a voltage source of 24VDC, 24VAC, 120VAC or 230VAC by wiring to appropriate input terminals. Single module mounted in an grey enclosure.
0.85lbs
WightBrand Information
The MR 100 Series Multivoltage Control Relays offer SPDT 10 Amp resistive contacts which may be operated by one of four input control voltages. A single relay may be energized from a voltage source of 24VDC, 24VAC, 120VAC or 230VAC by wiring to appropriate input terminals. Each relay position contains a red LED which indicates the relay coil is energized. Relays may be “snapped apart” from a standard 4 module assembly and used independently.
Why Choose the MR101 Relay?
- High Switching Capacity: Control heavy loads with total confidence. Ideal for driving motors, lighting, pumps, and other equipment without compromising performance.
-Robust Build for Demanding Environments: Built with high-durability materials, the MR101 operates reliably in extreme temperature and humidity, ensuring a long service life.
-Compact and Versatile Design: Its small footprint makes it easy to integrate into electrical panels, circuit boards, and projects with limited space, optimizing your layout.
-Superior Electrical Isolation: Protects your sensitive microcontrollers and control circuits from high-voltage spikes from the load, ensuring system integrity.
-Energy Efficient: Features low coil power consumption, making it a smart and economical choice for continuous operation.
Key Applications
The MR101 Relay is the ideal choice for a wide range of projects. See where it excels:
Industrial Automation: PLC control, contactor and motor activation, and heavy machinery systems.
Automotive Systems: Management of headlights, climate control systems, power locks, and other auxiliary circuits.
Home Automation (Smart Home): Perfect for DIY projects controlling lighting, irrigation systems, automatic gates, and security.
Electrical Control Panels: Simple and reliable integration into distribution panels and process control boards.
Key Technical Specifications
To ensure compatibility with your project, check the essential specifications:
MR101/C RELAY, SPDT W/LED, CA mode.
Contact Form: SPDT (Single Pole Double Throw) for maximum circuit flexibility (NO/NC).
Coil Voltage: Available in 12VDC and 24VDC versions (check model).
Max Contact Rating: Supports up to 10A at 250VAC (see datasheet for DC loads).
Integrated Protection: Suppression diode included to protect against reverse voltage on the coil.
(Note: Always consult the technical datasheet for detailed specifications and performance curves.)
